Pit Gauge

Measure surface pit, dent and gouge with precise and user friendly equipment.

  • High accuracy measurement
  • Durable and ergonomic design
  • Suitable for various industrial applications

Measure surface pit, dent and gouge with precise and user friendly equipment. This PIT GAUGE is the essential tool for manual pit inspection. You can choose Basic, Standard or Premium Kit. Standard and Premium Kit consists of magnetic arms which allow the Gauge to be mounted to a ferrous surface in vertical position or even upside down.

Types

Pit Gauge – PG150 – Basic



Part Name

Part Number

Qty.

Specifications

1

Center Base

PGCB150

1

Hard Anodized Aluminium – 150 x 18 x 38 mm

2

Digital Indicator

DIM543

1

Mitutoyo Dial Indicator 0.5″ (12.5 mm) Stroke

3

Indicator Tip

ITM543

1

Stainless Steel Needle

4

Carrying Bag

CBR230

1

Soft Bag – 230 x 170 x 65 mm



Pit Gauge – PG150 – Standard



Part Name

Part Number

Qty.

Specifications

1

Center Base

PGCB150

1

Hard Anodized Aluminium – 150 x 18 x 38 mm

2

Extension Arm

PGEA180

2

Hard Anodized Aluminium – 180 x 18 x 38 mm

3

Magnetic Arm

PGMA100

2

Hard Anodized Aluminium – 102 x 18 x 38 mm

4

Corner Base

PGCO90

1

Hard Anodized Aluminium – 88.5 x 18 x 38 mm

5

Digital Indicator

DIM543

1

Mitutoyo Dial Indicator 0.5″ (12.5 mm) Stroke

6

Indicator Tip

ITM543

1

Stainless Steel Needle

7

Carrying Case

CCPT44

1

Hard Case – 430 x 370 x 140 mm



Pit Gauge – PG150 – Premium



Part Name

Part Number

Qty.

Specifications

1

Center Base

PGCB150

1

Hard Anodized Aluminium – 150 x 18 x 38 mm

2

Extension Arm

PGEA180

4

Hard Anodized Aluminium – 180 x 18 x 38 mm

3

Magnetic Arm

PGMA100

2

Hard Anodized Aluminium – 102 x 18 x 38 mm

4

Corner Base

PGCO90

1

Hard Anodized Aluminium – 88.5 x 18 x 38 mm

5

Digital Indicator

DIM543

1

Mitutoyo Dial Indicator 0.5″ (12.5 mm) Stroke

6

Indicator Tip

ITM543

1

Stainless Steel Needle

7

Carrying Case

CCPT44

1

Hard Case – 430 x 370 x 140 mm



Features

  • Light weight and unique design
  • High precision instrument
  • Easy and quick assembling system
  • High-grade aluminum alloy
  • Durable wear resistance coating
  • Three different types to cover different requirements

Parts

Pit Gauge

Center Base – PGCB150

 The main part to mount dial indicator

Extension Arm – PGEA180

Use this part to extend the length of the Pit Gauge

Magnetic Arm – PGMA100

This part helps to measure pits in all positions (Overhead, Vertical and …)

Corner Base – PGCO90

This part is proper to measure pits in limited access corners

Indicator Tip – ITM543

Replaceable tip for dial indicator

Carrying Bag – CBR230

Soft and light weight bag to carry pit gauge

Digital Indicator – DIM543

This part indicates the value of the pit dent and etc.

Carrying Case – CCPT44

Hard Plastic case to carry all parts easily and safely
